30 Upgrade and Maintenance Manual RX1330 M3
Before you start
To rx P lus 6
0.09 Nm
ODD latch
M2 x 4 mm
(black)
C26192-Y10-C166
Phillips
PH1 / (+) No. 1
0.06 Nm
UFM nylon
screw
M3 x 4 mm
(white)
A3C40109082
Phillips
PH1 / (+) No. 1
0.4 Nm
TFM
M2.5 x 4 mm
(silver)
A3C40137316
Hexagon bolt
0.6 Nm
Front VGA
connector
UNC #4-40x7.8 mm
(silver)
V26827-B408-V989
Phillips
PH1 / (+) No. 1
0.4 Nm
Front panel on
QRL
M2.5 x 8 mm
(silver)
C26192-Y10-C174
Screw driver/
bit insert
Torque
Screw Usage Type
Table 2: List of used screws (not valid for Japan)
