Accessible drives
Figure 166: Disconnecting cables (example without 2nd 2.5-inch HDD backplane)
Ê Disconnect the ODD power cable and the SATA cable from the ODD.
Figure 167: Removing the ODD
Ê Press the ODD latch in direction of the arrow until it disengages (1).
Ê Pull the ODD out of the bay (2).
