RX200 S8
Upgrade and Maintenance Manual
189
Expansion cards and backu
p units
9.5.5.3
Disconnectin
g the FBU cable from t
he FBU
Figure 130:
Disconnecting the
FBU cable from
the FBU
Ê
Di
sconnect the FBU cable from the FBU.
9.5.5.4
Removing the FB
U from the ho
lder
Figure 131: Removing the FBU fr
om the holder
Ê
Pull the FBU at a slight angle out of the holder
.
188
190
