52 Upgrade and Maintenance Manual
RX200 S8
Basic hardware procedures
4.5 Reassembling
V CAUTION!
●
Before attaching the covers, make sure no unnecessary parts or tools
are left inside the server.
●
In order to comply with applicable EMC regulations (regulations on
electromagnetic compatibility) and satisfy cooling requirements, the
server must not run while the top / side cover is removed.
●
For further safety information, please refer to chapter "Important
information" on page 31.
4.5.1 Installing the housing cover
Figure 7: Installing the housing cover
Ê Position the housing cover so that it protrudes somewhat over the rear edge
(1).
Make sure that each bolt is positioned in the corresponding nut.
Ê Push the housing cover as far as it will go in the direction of the arrow (2).
