Fujitsu PRIMERGY RX200 S8 - Removing the Serial Interface; Preliminary Steps

276 Upgrade and Maintenance Manual RX200 S8
Serial interface
14.3 Removing the serial interface
14.3.1 Preliminary steps
Ê "Disabling SVOM boot watchdog functionality" on page 64
Ê "Disabling BitLocker functionality" on page 63
Ê "Shutting down the server" on page 46
Ê "Disconnecting the server from the mains" on page 47
Ê "Getting access to the component" on page 47
14.3.2 Removing the serial interface
Figure 212: Disconnecting the serial interface cable
Ê Disconnect the serial interface cable from the system board connector
"SERIAL 1".
Ê Remove the riser module 1 or the riser module2 as described in section
"Handling riser modules" on page 58.
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tools: tool-less
