98 Upgrade and Maintenance Manual
RX200 S8
Power supply
6.3.1 Preliminary steps
No steps needed.
6.3.2 Removing a power supply unit
Ê Remove the power cord from the dedicated power supply unit as described
in section "Disconnecting the server from the mains" on page 47
I Keep the power cord for future use.
Figure 30: Unlocking and removing the power supply unit
Ê Push the handle of the power supply unit halfway upward in the direction of
the arrow (1).
Ê Push the lock in direction of the arrow (2).
Ê Grip the handle and pull out the power supply unit in the direction of the
arrow (3).
V CAUTION!
Never leave the bay for the power supply unit empty for more than two
minutes during operation. Otherwise, excessive temperatures could
damage system components.
