RX200 S8
Upgrade and Maintenance Manual 159
Expansion cards and backup units
9.4.3 Removing an expansion card - slot 1-3
9.4.3.1 Preliminary steps
Ê "Disabling BitLocker functionality" on page 63
Ê "Shutting down the server" on page 46
Ê "Disconnecting the server from the mains" on page 47
Ê "Getting access to the component" on page 47
Ê Remove the corresponding riser module as described in section "Removing
the riser module 1" on page 58 or "Removing the riser module 2" on
page 59.
9.4.3.2 Removing the expansion card - slot 1-3
Figure 93: Removing the expansion card - slot 1
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tools: tool-less
