334 Upgrade and Maintenance Manual RX200 S8
Appendix
17.3 Onboard settings
Figure 263: Jumper
iRMC
external connectors
INDICATE
CSS
TPM
LAN
CTRL
Battery
VGA
USB 2
USB 3
Shared
LAN
LAN 2
Management
LAN
Slot riser card / slot 2 and 3
CPU 2 DIMM 3F
CPU 2 DIMM 2F
CPU 2 DIMM 1E
CPU 2 DIMM 2E
CPU 2 DIMM 3E
CPU 2 DIMM 1F
CPU 2 DIMM 1G
CPU 2 DIMM 2G
CPU 2 DIMM 3H
CPU 2 DIMM 2H
CPU 2 DIMM 1H
CPU 2 DIMM 3G
PCH
CPU 1 DIMM 1A
CPU 1 DIMM 2A
CPU 1 DIMM 3B
CPU 1 DIMM 2B
CPU 1 DIMM 1B
CPU 1 DIMM 3A
CPU 1 DIMM 3D
CPU 1 DIMM 2D
CPU 1 DIMM 1C
CPU 1 DIMM 2C
CPU 1 DIMM 3C
CPU 1 DIMM 1D
1
CN101
J9
FAN 11/12 SYS
SATA 1
SAS 1
SMB
SAS
Front
Panel
Front
VGA
PWR 1
BP
PWR
Front LAN M
CPU 2
CPU 1
FAN 9/10 SYS
FAN 7/8 SYS
FAN 5/6 SYS
FAN 3/4 SYS
FAN 1/2 SYS
USB 1
Slot riser card / slot 1
Slot riser card / slot 4
Slot 3
Slot 2
UFM
PWR 2
SERIAL 1
1
NC-SI
SKU Key
Setting
CN101
Password Skip/
Recovery BIOS
Jumper Description
J9 CMOS Clear
1
Default
1
Password Skip
enabled
1
Recovery BIOS
enabled
Default Clear CMOS
Jumper settings
1
