192 Upgrade and Maintenance Manual
RX200 S8
Expansion cards and backup units
Ê If the BBU status does not change after 12 hours, please try to initiate the
recalibration process manually using the ServerView RAID Manager.
I If this procedure still does not fix the BBU status, please contact your
local Fujitsu customer service partner.
9.5.7 Replacing an FBU
V CAUTION!
●
Dispose of used battery properly. Keep away from children.
●
Do not throw flash backup units into the trash can. Batteries must be
disposed of in accordance with local regulations concerning special
waste.
9.5.7.1 Preliminary steps
Ê "Disabling SVOM boot watchdog functionality" on page 64
Ê "Shutting down the server" on page 46
Ê "Disconnecting the server from the mains" on page 47
Ê "Getting access to the component" on page 47
Ê "Removing the riser module 3" on page 60
9.5.7.2 Removing the defective FBU
Ê Remove the FBU with the holder as described in section "Removing the FBU
with the holder" on page 188.
Ê Disconnect the FBU cable from the FBU as described in section
"Disconnecting the FBU cable from the FBU" on page 189.
Ê Remove the FBU from the holder as described in section "Removing the
FBU from the holder" on page 189.
Upgrade and Repair Unit
(URU)
Hardware: 15 minutes
Tools: tool-less
