306
Upgrade and Mai
ntenance Manual
RX200
S8
System board and co
mponents
15.
6.2
Rem
ovin
g the d
efec
tive
syst
em bo
ard
Ê
Disconnect all cables from the system board.
Figure 236: Removing the fan cage
Ê
Remove the four scr
ews (1).
Ê
Push the fan cage somewhat in direction of the arro
w (2) to disengage the
hooks (see close-up).
Ê
Remove the fan cage upward (3).
305
307
