RX200 S8
Upgrade and Maintenance Manual 93
Power supply
6.2 Installing a power supply unit
6.2.1 Preliminary steps
No steps needed.
6.2.2 Removing the dummy cover
Figure 23: Removing the dummy cover
Ê Press the two grips together as indicated by the arrows (1) and remove the
dummy cover (2).
V CAUTION!
Keep the dummy cover for future use. If the power supply unit is removed
and not replaced with a new one, the dummy cover must be reinstalled
due to cooling, to comply with applicable EMC regulations (regulations
on electromagnetic compatibility), and to protect against fire.
Customer Replaceable Unit
(CRU)
Hardware: 5 minutes
Tools: tool-less
