17 Appendix
17.1 Mechanical overview
17.1.1 Server front
Figure 252: Front side 4x 2.5-inch HDDs
Figure 253: Front side 8x 2.5-inch HDDs
Pos. Component
1 4x 2.5-inch hard disk drives / dummy modules
2 Front VGA/LAN module (option)
3ID card
4 ODD (option) / dummy cover
5 Front panel and indicators
Pos. Component
1 8x 2.5-inch hard disk drives / dummy modules
2 Front VGA/LAN module
3ID card
4 Front panel and indicators
