240
Upgrade and Mai
ntenance Manual
RX200
S8
Optical disk drive
12.3.2
Removing the ODD
Figure 168: Removing the ODD
Ê
Press the lock in direction of the arrow unti
l it disengages (1).
Ê
Push the ODD out of the bay (2)
.
Figure 169: Removing the ODD
out of the mounting frame
Ê
Pull the mounting frame outward on both sides (1).
239
