RX200 S8 Upgrade and Maintenance Manual 99
Power supply
6.3.3 Installing the dummy cover
Figure 31: Installing the dummy cover
Ê Push the dummy cover into the right bay until it clicks into place.
Ensure that the marking "TOP" is right and the upper rear cant of the dummy
cover fits under the PSU cage.
6.3.4 Concluding steps
No steps needed.
6.4 Replacing a power supply unit
V CAUTION!
● When replacing a power supply unit in a non-redundant PSU
configuration, the server must be switched off first.
Customer Replaceable Unit
(CRU)
Hardware: 5 minutes
Tools: tool-less
