RX200 S8
Upgrade and Maintenance Manual 263
Front panel and front VGA/LAN module
13.6 Replacing the front panel board
Note on system information backup / restore
I The front panel board contains the Chassis ID EPROM that contains
system information like server name and model, housing type, serial
number and manufacturing data.
To avoid the loss of non-default settings when replacing the system
board, a backup copy of important system configuration data is
automatically stored from the system board NVRAM to the Chassis ID
EPROM. After replacing the system board the backup data is restored
from the front panel board to the new system board.
V CAUTION!
For that reason the front panel board and system board must not be
replaced simultaneously! In this case, restoring the system configuration
data on the system board would fail.
13.6.1 Preliminary steps
Ê "Locating the defective server" on page 43
Ê "Disabling SVOM boot watchdog functionality" on page 64
Ê "Disabling BitLocker functionality" on page 63
Ê "Shutting down the server" on page 46
Ê "Disconnecting the server from the mains" on page 47
Ê "Getting access to the component" on page 47
Ê "Locating the defective component" on page 45
Field Replaceable Unit
(FRU)
Hardware: 10 minutes
Software: 5 minutes
Tools: Phillips PH1 / (+) No. 1 screw driver
