RX200 S8
Upgrade and Maintenance Manual 27
Before you start
2.3 Tools you need at hand
When preparing the maintenance task, ensure that all required tools are
available according to the overview below. You will find a list of required tools at
the beginning of each procedure.
Screw driver/
bit insert
Screw Usage Type
Phillips
PH2 / (+) No. 2
Chassis
M3 x 4.5 mm
(silver)
C26192-Y10-
C67
Phillips
PH2 / (+) No. 2
System board
M3 x 6 mm
(silver)
C26192-Y10-
C68
Special bit insert TPM screw
REM 3 x 15 mm
(black)
C26192-Y10-
C176
Phillips
PH1 / (+) No. 1
UFM nylon
screw
M3 x 4.5 mm
(white)
A3C40109082
Phillips
PH1 / (+) No. 1
TFM module M2.5 x 4 mm
(silver)
C26192-Y10-
C103
Table 2: List of used screws (not applicable for the Japanese market)
