324 Upgrade and Maintenance Manual RX200 S8
Appendix
Figure 256: Interior (example: 8x 2.5-inch HDDs)
Pos. Component
1 Up to 2 power supply units
2 Riser module 1
3 Riser module 2
4 Riser module 3
5CPU 1
6 Main memory CPU 1
7CPU 2
8 Main memory CPU 2
9 Fan modules
10 8x 2.5-inch hard disk drives / dummy modules
11 Top side: front VGA/LAN module (option)
