Fujitsu PRIMERGY RX2540 M1 - Installing 3.5-Inch HDD Modules; Preliminary Steps

RX2540 M1 Upgrade and Maintenance Manual 115
Hard disk drives / solid state drives
7.2.2 Installing 3.5-inch HDD modules
7.2.2.1 Preliminary steps
Ê Locate the correct drive bay as described in section "3.5-inch cage
configurations HDD / SSD" on page 112.
6 HDD5
7 HDD6
8 HDD7
9 HDD8
10 HDD9
11 HDD10
12 HDD11
Customer Replaceable Unit
(CRU)
Hardware: 5 minutes
Tools: tool-less
Bay number SV RAID Manager (one SAS RAID
controller)
