RX2540 M1
Upgrade and Maintenance Manual 377
System board and components
14.4.1.2 Installing the TPM
Figure 257: TPM kit
Figure 258: TPM mounting location
1 TPM (Trusted Platform Module) 3 Special screw for TPM
2 TPM spacer
I The black TPM spacer is
not used in this server.
4 TPM bit insert for TPM special
screw
1 TPM connector 2 Cut-out for TPM spacer
