Ê Install the riser module as described in section "Installing the riser module 1
(FL)" on page 214.
9.6.2.8 Installing the system air duct
I If no GPGPU card is installed you have to order a new air duct to direct
the airflow directly onto the CPU heat sinks and memory slots.
Ê Install the system air duct as described in section "Installing the air duct" on
page 61.
9.6.2.9 Concluding steps
Ê "Reassembling" on page 61
Ê "Connecting the server to the power source" on page 66
Ê "Switching on the server" on page 67
Ê "Enabling BitLocker functionality" on page 92
9.6.3 Installing a GPGPU card in riser module 2
9.6.3.1 Preliminary steps
Ê "Disabling or suspending BitLocker functionality" on page 69
Ê "Disabling SVOM boot watchdog functionality" on page 70
Ê "Shutting down the server" on page 53
Ê "Disconnecting power cords" on page 54
Ê "Getting access to the component" on page 55
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Software: 5 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver
