13.3.3.4 Installing the new front VGA connector
Ê Install the new front VGA connector as described in section "Installing the
front VGA" on page 346.
13.3.3.5 Re-installing the front panel module
Ê "Removing the front panel card" on page 342.
13.3.3.6 Concluding steps
Ê "Installing the fan box" on page 156
Ê "Reassembling" on page 61
Ê "Connecting the server to the power source" on page 66
Ê "Switching on the server" on page 67
Ê "Enabling BitLocker functionality" on page 92
13.4 Front USB3.0 connector
13.4.1 Installing the front USB3.0 connector
13.4.1.1 Preliminary steps
Ê "Disabling or suspending BitLocker functionality" on page 69
Ê "Locating the defective server" on page 51
Ê "Shutting down the server" on page 53
Ê "Disconnecting power cords" on page 54
Ê "Getting access to the component" on page 55
Field Replaceable Unit
(FRU)
Hardware: 10 minutes
Tools: hexagon SW5
