RX2540 M1
Upgrade and Maintenance Manual 411
15 Cables
This chapter provides information on how to connect, disconnect and route
cables.
Safety notes
V CAUTION!
●
Always hold cables by their connectors when disconnecting them.
Never pull on the cable to disconnect cables.
●
Ensure that none of the cables are scraped, strained or otherwise
damaged while replacing system components.
●
Immediately replace cables with damaged shielding.
●
Always use shielded network cables.
15.1 List of used cables
15.1.1 3.5-inch versions
No Name Cable number Routing
C1
CBL FRONT
PANEL GTL
T26139-Y4015-V301
Front panel board to system
board
C2 CBL_USB30_650 T26139-Y3999-V505
Front USB3.0 to system
board
C3
LTG SATA
2XGER 750
T26139-Y3928-V205 ODD to system board
C4
CBL_FRONT_V
GA
T26139-Y3994-V301 Front VGA to system board
C5 CBL PWR 2CO
400
T26139-Y3986-V302 ODD to SAS BP 1
C6
CBL PWR SAS-
BP 660
T26139-Y3939-V503 SAS BP 1 to system board
Table 4: List of used cables
