Fujitsu PRIMERGY RX2540 M1 - 8.3 Removing the fan box

154 Upgrade and Maintenance Manual RX2540 M1
System fan
8.3 Removing the fan box
8.3.1 Preliminary steps
Ê "Locating the defective server" on page 51
Ê "Shutting down the server" on page 53
Ê "Disconnecting power cords" on page 54
Ê "Getting access to the component" on page 55
8.3.2 Removing the fan box
Figure 66: Removing a fan module (A)
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tools: screw driver, hexagonal cross SW5
