Figure 278: Installing the stabilizer bar
Ê Insert the stabilizer bar.
Ê Fasten the stabilizer bar with the 5 screws.
Ê Verify the settings on the new system board (see figure "Onboard settings"
on page 435).
14.7.3.2 Swapping processors
Preparing the processor socket load plates on the new system board
Ê "Opening the load plate" on page 288
Removing processors from the defective system board
Ê Carefully remove the processors from their sockets on the defective system
board as described in "Removing a processor" on page 298.
V CAUTION!
Remove and reinstall one processor at a time. Do not remove the
second processor from the defective system board until the first
processor has been installed on the new system board.
