Fujitsu PRIMERGY RX2540 M1 - Removing Riser Module 1 (HL); Preliminary Steps; Removing the Riser Module 1 (HL)

RX2540 M1 Upgrade and Maintenance Manual 193
Expansion cards and backup units
Ê "Enabling SVOM boot watchdog functionality" on page 86
Ê "Enabling BitLocker functionality" on page 92
9.5.2 Removing riser module 1 (HL)
9.5.2.1 Preliminary steps
Ê If applicable, "Locating the defective server" on page 51
Ê "Disabling or suspending BitLocker functionality" on page 69
Ê "Shutting down the server" on page 53
Ê Remove all external cables from the expansion card to be removed.
Ê "Disconnecting power cords" on page 54
Ê "Getting access to the component" on page 55
Ê If applicable, disconnect internal cables from the expansion board.
9.5.2.2 Removing the riser module 1 (HL)
Ê If applicable, "Removing an SFP+ transceiver module" on page 175.
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Software: 5 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver
