260 Upgrade and Maintenance Manual RX2540 M1
Expansion cards and backup units
9.8.3 Removing the DynamicLoM module
9.8.3.1 Preliminary steps
Ê "Disabling SVOM boot watchdog functionality" on page 70
Ê "Shutting down the server" on page 53
Ê "Disconnecting power cords" on page 54
Ê "Getting access to the component" on page 55
9.8.3.2 Removing the DynamicLoM module
Figure 164: Removing the DynamicLoM module
Ê Remove the screws.
Ê Remove the DynamicLoM module.
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tool: – Phillips PH0 / (+) No. 0 screw driver
– hexagon screw driver 5 mm
