Figure 163: Inserting the DynamicLoM module
Ê Install the DynamicLoM module with the bottom side above.
I For DynamicLoM D3275:
Remove the protective foil.
Ê Fasten it with the three screws on the bolts (M3x 4.5 mm).
9.8.2.4 Concluding steps
Ê "Reassembling" on page 61
Ê "Connecting the server to the power source" on page 66
Ê "Switching on the server" on page 67
Ê Inform the customer about changed WWN and MAC addresses. For further
information, refer to section "Looking up changed MAC / WWN addresses"
on page 93.
Ê "Updating the NIC configuration file in a Linux environment" on page 90
Ê "Configuring LAN teaming" on page 97
Ê "Enabling SVOM boot watchdog functionality" on page 86
Ê Start Emulex PXESelect Utility
