RX2540 M1 Upgrade and Maintenance Manual 327
Accessible drives
Ê Remove the cover plate of the front panel module.
Ê Turn the cover plate of the front panel module upside down.
Figure 217: Removing the ODD latch
Ê Remove ODD.
Figure 218: Installing the dummy cover
Ê Insert the ODD dummy module
