Remove the corresponding riser module, see "Removing a riser module" on
page 72.
Removing the defective riser card
▶
Remove the expansion card, see "Removing an expansion card" on
page 278.
Figure 182: Removing the riser card
▶
Remove the four screws (see circles).
▶
Remove the riser card.
Expansion cards and backup units
318 Upgrade and Maintenance Manual RX2540 M7
