Fujitsu PRIMERGY TX2550 M5 Upgrade And Maintenance Manual

6 Power supply unit (PSU)
6.1 Safety notes
CAUTION
▶
Do not disassemble the PSU. Doing so may cause electric shock.
▶
Areas around the PSU may remain extremely hot after shutdown.
After shutting down the server
, wait for hot components to cool
down before removing the PSU.
▶
When installing a PSU, ensure that the connector of the PSU is not
damaged or bent.
▶
The PSU is heavy
, so handle it carefully. If you drop it by mistake,
injuries may result.
▶
For more information, see "Important information" on page 33.
6.2 Basic information
AC PSU
The server can be equipped with up to two AC PSUs.
In its basic configuration, the server has one PSU that adjusts automatically to
any mains voltage in the range of 100 V - 240 V (AC PSU Platinum) or 200
V -
240 V (AC PSU Titanium). Besides the PSU, a second PSU can be installed
optionally to serve as a redundant power supply. If one PSU fails, the second
PSU in the redundant configuration ensures operation can continue
uninterrupted and the defective PSU can be replaced during operation (hot-
plug). The second PSU can be installed during operation.
CAUTION
The AC PSU adjusts automatically to any mains voltage in the range
from 100
V - 240 V (AC PSU Platinum) or 200 V - 240 V (AC PSU
Titanium).
▶
You may only operate the server if its rated voltage range
corresponds to the local mains voltage.
TX2550 M5 Upgrade and Maintenance Manual 143

Fujitsu PRIMERGY TX2550 M5 Specifications

General

Tcase	78 °C
Scalability	2S
Processor cache	13.75 MB
Processor cores	10
Processor model	4210
System bus rate	- GT/s
Processor socket	LGA 3647 (Socket P)
Processor threads	20
Processor codename	Cascade Lake
Execute Disable Bit	Yes
Processor frequency	2.2 GHz
Processor lithography	14 nm
Processor manufacturer	Intel
Processor package size	76.0 x 56.5 mm
Processor boost frequency	3.2 GHz
Processor operating modes	64-bit
Supported instruction sets	AVX-512
Thermal Design Power (TDP)	85 W
Number of processors installed	1
Maximum number of PCI Express lanes	48
Memory types supported by processor	DDR4-SDRAM
Memory clock speeds supported by processor	2400 MHz
Maximum internal memory supported by processor	1024 GB
Memory slots	12
Internal memory	16 GB
Memory clock speed	2933 MHz
Maximum internal memory	1500 GB
HDD size	2.5 \
RAID levels	0, 1, 5, 6, 10, 50, 60
HDD interface	Serial ATA, Serial Attached SCSI (SAS)
Optical drive type	No
Total storage capacity	0 GB
Maximum storage capacity	- TB
Number of HDDs supported	8
Chassis type	Tower
Product color	Black, Red
Operating system installed	-
Compatible operating systems	Microsoft Hyper-V Server 2016 Microsoft Windows Server 2016 Datacenter Microsoft Windows Server 2016 Standard Microsoft Windows Server 2016 Essentials Microsoft Windows Storage Server 2016 Standard Microsoft Hyper-V Server 2012 R2 Microsoft Windows Server 2012 R2 Datacenter Microsoft Windows Server 2012 R2 Standard Microsoft Windows Server 2012 R2 Essentials Microsoft Windows Storage Server 2012 R2 Standard VMware vSphere 6.5 VMware vSphere 6.0 SUSE Linux Enterprise Server 12 Red Hat Enterprise Linux 7 Red Hat Enterprise Linux
Power supply	800 W
Cabling technology	10/100/1000Base-T(X)
Ethernet interface type	Gigabit Ethernet
Operating temperature (T-T)	5 - 45 °C
Operating relative humidity (H-H)	10 - 85 %
Certification	CB, RoHS, WEEE, GS, CE, CSAc/us, FCC Class A, VCCI, KN32, KN35, CCC, C-Tick
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	6
PCI Express slots version	3.0
On-board graphics card model	Not available
Processor ARK ID	193384

Weight and Dimensions

Depth	177 mm
Width	448 mm
Height	736 mm
