"Installing the PCI air duct" on page 89
.
▶
"Installing the system air duct" on page 68.
▶
"Reassembling" on page 68.
▶
"Connecting the power cord" on page 82.
▶
"Switching on the server" on page 83.
12.7.2 Removing the ultraslim ODD from the ultraslim
ODD adapter
Upgrade and Repair Unit
(URU)
Hardware: 10 minutes
Tools: Phillips PH0 / (+) No. 0 screw driver
Preliminary steps
▶
"Removing backup and optical disk media" on page 110.
▶
"Shutting down the server" on page 49.
▶
"Disconnecting the power cord" on page 50.
▶
"Getting access to the component" on page 51.
▶
The front cover only needs to be removed in order to remove or
install accessible drive dummy covers.
▶
"Removing the system air duct" on page 67
.
▶
"Removing the PCI air duct" on page 88.
▶
If applicable, "Removing the riser module" on page 86.
▶
If applicable, remove the expansion card, see "Removing an expansion
card" on page 358.
▶
Remove the fan bridge, see "Handling the fan bridge" on page 92.
▶
If applicable, "Removing the 4x 3.5-inch HDD extension box" on page 281.
Accessible drives
TX2550 M5 Upgrade and Maintenance Manual 459
