For Japan
In order to setup the ESXi, see the corresponding version of the
"VMware vSphere Software Description" from the following URL and
reinstall ESXi to the M.2 SSD.
https://jp.fujitsu.com/platform/server/primergy/software/vmware/manual/
14.6.3 Removing an M.2 SSD
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tools:
– Phillips PH1 / (+) No. 1 screw driver
– Hexagon screw driver (for moving the screw to another hexagon
stand-of
f)
Preliminary steps
▶
"Shutting down the server" on page 49
.
▶
"Disconnecting the power cord" on page 50.
▶
"Getting access to the component" on page 51.
▶
"Removing the system air duct" on page 67.
▶
"Removing the PCI air duct" on page 88.
▶
If applicable, remove the riser module, see "Removing the riser module" on
page 86.
▶
"Removing the crossbar" on page 90.
▶
If applicable, remove the expansion card, see "Removing an expansion
card" on page 358.
System board and components
496 Upgrade and Maintenance Manual TX2550 M5
