Concluding steps
▶
Dispose of the CMOS battery in accordance with local regulations
concerning special waste.
▶
"Reassembling" on page 68.
▶
"Connecting the power cord" on page
82.
▶
"Switching on the server" on page 83.
▶
BIOS settings are automatically reloaded. Time and date must be set
manually, see "Verifying the system time settings" on page 126.
14.4 Trusted Platform Module (TPM)
14.4.1 TPM kit
Figure 308: TPM installation kit
1 TPM
2 TPM spacer
3
Special screw for TPM
4 TPM bit insert for TPM special screw
14.4.2 Installing the TPM
Field Replaceable Unit
(FRU)
Hardware: 5 minutes
Software: 5 minutes
System board and components
476 Upgrade and Maintenance Manual TX2550 M5
