Tools: – Bit screw driver
– TPM bit insert (*)
(*)
For Japan:
–
TPM module fixing tool (S26361-F3552-L909)
Preliminary steps
▶
"Suspending BitLocker functionality" on page
107
.
▶
"Shutting down the server" on page 49.
▶
"Disconnecting the power cord" on page 50.
▶
"Getting access to the component" on page 51.
▶
"Removing the PCI air duct" on page 88.
▶
If applicable, remove the riser module, see "Removing the riser module" on
page 86.
Installing the TPM
Figure 309: Position for the TPM spacer
System board and components
