Concluding steps
▶
If applicable, install the expansion card, see "Installing an expansion card"
on page 346
.
▶
"Installing the crossbar" on page 91.
▶
If applicable, install the riser module, see "Installing the riser module" on
page 87.
▶
"Installing the PCI air duct" on page 89.
▶
"Installing the system air duct" on page 68.
▶
"Reassembling" on page 68.
▶
"Connecting the power cord" on page 82.
▶
"Switching on the server" on page 83.
14.6.4 Replacing the M.2 SSD
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Software: 15 minutes
Tools: Phillips PH1 / (+) No. 1 screw driver
Preliminary steps
▶
"Locating the defective server" on page 47
.
▶
"Shutting down the server" on page 49.
▶
"Disconnecting the power cord" on page 50.
▶
"Getting access to the component" on page 51.
▶
"Removing the system air duct" on page 67.
▶
"Removing the PCI air duct" on page 88.
▶
If applicable, remove the riser module, see "Removing the riser module" on
page 86.
▶
"Removing the crossbar" on page 90.
System board and components
