Installing the dummy cover
Figure 70: Installing the dummy cover
▶
Insert the dummy cover into the empty bay with the impressed arrow symbol
facing to the left (see circle).
▶
Push the dummy cover into its bay until it locks in place.
CAUTION
▶
Always install dummy covers into unused bays to comply with
applicable EMC regulations and satisfy cooling requirements.
Concluding steps
No steps needed.
6.3.3 Replacing a hot-plug PSU
Customer Replaceable
Unit (CRU)
Hardware: 5 minutes
Tools: tool-less
CAUTION
▶
When replacing a PSU in a non-redundant PSU configuration, the
server must be switched off first.
▶
Replace the PSU after specifying the one that breaks down at work
by revitalization.
Power supply unit (PSU)
TX2550 M5 Upgrade and Maintenance Manual 153
