"Connecting the power cord" on page 82
.
▶
"Switching on the server" on page 83.
▶
"Resuming BitLocker functionality" on page 130.
7.9 SAS expander board
7.9.1 Installing the SAS expander board
Field Replaceable Unit
(FRU)
Hardware: 10 minutes
Software: 10 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver
After installing or removing the extension box, never forget to change
the system information using the Chassis ID Prom Tool.
Preliminary steps
▶
"Suspending BitLocker functionality" on page 107.
▶
"Shutting down the server" on page 49.
▶
"Disconnecting the power cord" on page 50.
▶
"Getting access to the component" on page 51.
▶
"Removing the system air duct" on page 67.
▶
Remove the fan bridge, see "Handling the fan bridge" on page 92.
Hard disk drive (HDD) / solid state disk (SSD)
306 Upgrade and Maintenance Manual TX2550 M5
