Connect the power cable C6 to the connector "PWR3" on the system board.
▶
If applicable, connect the OOB cable, see "Replacing the OOB cable" on
page
554
.
For the cable plan, see "Appendix B" on page 589
.
Installing HDD modules into the 8x 2.5-inch HDD/SSD extension box
▶
"Reassembling" on page 68.
▶
Install HDD modules or HDD dummy modules into the additional HDD bays,
see
"Installing a 2.5-inch HDD/SSD module" on page 219 and "Installing a
2.5-inch dummy module" on page 222.
For more information on HDD mounting order, see "2.5-inch HDD/SSD
configurations" on page 202.
Concluding steps
▶
Install the fan bridge, see "Handling the fan bridge" on page 92.
▶
"Installing the system air duct" on page 68.
▶
"Reassembling" on page 68.
▶
"Connecting the power cord" on page 82.
▶
"Switching on the server" on page 83.
▶
Update the system information of your server using the Chassis ID Prom
Tool, see "Using the Chassis ID Prom Tool" on page 136. Select the
corresponding system name.
▶
"Resuming BitLocker functionality" on page 130.
7.6.3 Removing the 8x 2.5-inch HDD/SSD extension
box
Upgrade and Repair Unit
(URU)
Hardware: 10 minutes
Software: 10 minutes
Hard disk drive (HDD) / solid state disk (SSD)
