17.2 Replacing the OOB cable
Field Replaceable Unit
(FRU)
Average task duration:
10 minutes
Tools: tool-less
There are different OOB cables depending on the OOB configuration.
Preliminary steps
"Locating the defective server" on page 47
.
"Shutting down the server" on page 49.
"Disconnecting the power cord" on page 50.
"Getting access to the component" on page 51.
"Removing the system air duct" on page 67.
Remove the fan bridge, see "Handling the fan bridge" on page 92.
Replacing the OOB cable
Replacing the OOB cable is illustrated by the example with two
backplanes and extension box. For other configurations see the cable
plans in "Appendix B" on page
589
.
Disconnect the defective OOB cable from all connectors.
Cables
554 Upgrade and Maintenance Manual TX2550 M5
