Close the locking lever on the top cover (1). This will push the top cover shut
engaging the locking mechanism (2).
4.5.3.3
Installing the server in the rack
CAUTION
At least two people are needed to position the server on the rack rails.
(For Japan, see "安全上のご注意".)
For configurations below 32 kg:
At least two people are needed to lift the server into the
rack cabinet.
For configurations below 55 kg:
At least three people are needed to lift the server into
the rack cabinet.
For configurations above 55 kg:
At least four people are needed to lift the server into the
rack cabinet.
Additionally, a lifter is required in the following cases:
–
The server weighs more than 50 kg.
–
The server weighs more than 21 kg and is to be installed above the height of
25 U.
Basic hardware procedures
72 Upgrade and Maintenance Manual TX2550 M5
