Installing accessible drive dummy covers
▶
If applicable, install accessible drive filler covers, see "Removing an
expansion card" on page 358
.
▶
If applicable, install accessible drive covers, see "Removing accessible
drive covers" on page 101.
Concluding steps
▶
If applicable, install the expansion card, see "Installing an expansion card"
on page 346.
▶
Install the fan bridge, see "Handling the fan bridge" on page 92.
▶
If applicable, "Installing the riser module" on page 87.
▶
"Installing the PCI air duct" on page 89.
▶
"Installing the system air duct" on page 68.
▶
"Reassembling" on page 68.
▶
"Connecting the power cord" on page 82.
▶
"Switching on the server" on page 83.
▶
If applicable, "Reconfiguring the backup software solution" on page 117.
12.5 Replacing accessible drives
Upgrade and Repair Unit
(URU)
Hardware: 15 minutes
Tools: Slotted screw driver (for bending in or out accessible drive
mounting brackets)
Preliminary steps
▶
"Locating the defective server" on page 47
.
▶
"Removing backup and optical disk media" on page 110.
Accessible drives
442 Upgrade and Maintenance Manual TX2550 M5
