"Verifying and configuring the backup software solution" on page
110.
▶
"Shutting down the server" on page 49.
▶
"Disconnecting the power cord" on page 50.
▶
"Getting access to the component" on page 51.
Removing the front cover is not required in order to replace an
accessible drive.
▶
"Removing the system air duct" on page 67.
▶
"Removing the PCI air duct" on page
88.
▶
If applicable, "Removing the riser module" on page 86.
▶
If applicable, remove the expansion card, see "Removing an expansion
card" on page 358.
▶
Remove the fan bridge, see "Handling the fan bridge" on page 92.
Removing the defective accessible drive
▶
Remove all cables from the accessible drive.
▶
Remove the accessible drive, see "Removing an accessible drive" on
page 441.
Installing the new accessible drive
▶
Install the accessible drive, see "Installing an accessible drive" on page 435.
▶
Connect all cables to their original accessible drive connectors, see
"Cables" on page 545.
Concluding steps
▶
If applicable, install the expansion card, see "Installing an expansion card"
on page 346.
▶
Install the fan bridge, see "Handling the fan bridge" on page 92.
▶
If applicable, "Installing the riser module" on page 87.
▶
"Installing the PCI air duct" on page 89.
Accessible drives
TX2550 M5 Upgrade and Maintenance Manual 443
