Fujitsu PRIMERGY TX2550 M5 - Replacing the Power Distribution Board

▶
"Switching on the server" on page 83
.
▶
"Resuming BitLocker functionality" on page 130.
6.4.3 Replacing the power distribution board
Field Replaceable Unit
(FRU)
Hardware: 10 minutes
Tools: Phillips PH1 / (+) No. 1 screw driver
Preliminary steps
▶
"Locating the defective server" on page 47
.
▶
"Suspending BitLocker functionality" on page 107.
▶
"Shutting down the server" on page 49.
▶
"Disconnecting the power cord" on page 50.
▶
"Getting access to the component" on page 51.
▶
"Removing the system air duct" on page 67.
▶
"Removing the PCI air duct" on page 88.
▶
If applicable, "Removing the riser module" on page 86.
▶
"Removing the crossbar" on page 90.
Removing the power distribution board
▶
Remove the PSU from bay 2, see "Removing a hot-plug PSU" on page 148.
▶
Remove the power distribution board, see "Removing the power distribution
board" on page 158.
Power supply unit (PSU)
TX2550 M5 Upgrade and Maintenance Manual 161
