7.2 Basic information
The HDD or SSD and the installation frame together make up the HDD module
or SSD module.
The server is shipped with one of the following HDD or SSD subsystems:
–
3.5-inch HDD subsystem
–
2.5-inch HDD/SSD subsystem
3.5-inch HDD subsystem
Up to four
, eight or 12 3.5-inch SAS/SA
TA HDD modules can be installed. The
HDD module is connected to the HDD backplane wirelessly. This allows HDD
modules to be plugged in or pulled out easily.
Hybrid configurations of SAS and SATA HDD modules are supported in
combination with an optional HDD controller.
In addition two non-hot-plug HDDs/SSDs can be installed.
For upgrading your system to other HDD configurations, see the following
table:
4x to 8x 3.5-inch HDD/SSD
configurations
see "Upgrading to 8x 3.5-inch HDD
configurations" on page
195
8x to 12x 3.5-inch HDD/SSD
configurations
see "Installing the 4x 3.5-inch HDD
extension box" on page 277
2.5-inch HDD/SSD subsystem
Up to eight, 16, 24, or 32 2.5-inch SAS/SATA HDD/SSD modules can be
installed.
The HDD/SSD modules are connected to the HDD backplane wirelessly. This
allows HDD/SSD modules to be plugged in or pulled out easily. If the server
has a corresponding RAID configuration, defective HDD/SSD modules can
also be replaced during operation.
Hybrid configurations of SAS and SATA SSD / BC-SAS and BC-SATA HDD
modules are supported in combination with an optional HDD controller.
Hard disk drive (HDD) / solid state disk (SSD)
164 Upgrade and Maintenance Manual TX2550 M5

Fujitsu PRIMERGY TX2550 M5 Specifications

General

Tcase	78 °C
Scalability	2S
Processor cache	13.75 MB
Processor cores	10
Processor model	4210
System bus rate	- GT/s
Processor socket	LGA 3647 (Socket P)
Processor threads	20
Processor codename	Cascade Lake
Execute Disable Bit	Yes
Processor frequency	2.2 GHz
Processor lithography	14 nm
Processor manufacturer	Intel
Processor package size	76.0 x 56.5 mm
Processor boost frequency	3.2 GHz
Processor operating modes	64-bit
Supported instruction sets	AVX-512
Thermal Design Power (TDP)	85 W
Number of processors installed	1
Maximum number of PCI Express lanes	48
Memory types supported by processor	DDR4-SDRAM
Memory clock speeds supported by processor	2400 MHz
Maximum internal memory supported by processor	1024 GB
Memory slots	12
Internal memory	16 GB
Memory clock speed	2933 MHz
Maximum internal memory	1500 GB
HDD size	2.5 \
RAID levels	0, 1, 5, 6, 10, 50, 60
HDD interface	Serial ATA, Serial Attached SCSI (SAS)
Optical drive type	No
Total storage capacity	0 GB
Maximum storage capacity	- TB
Number of HDDs supported	8
Chassis type	Tower
Product color	Black, Red
Operating system installed	-
Compatible operating systems	Microsoft Hyper-V Server 2016 Microsoft Windows Server 2016 Datacenter Microsoft Windows Server 2016 Standard Microsoft Windows Server 2016 Essentials Microsoft Windows Storage Server 2016 Standard Microsoft Hyper-V Server 2012 R2 Microsoft Windows Server 2012 R2 Datacenter Microsoft Windows Server 2012 R2 Standard Microsoft Windows Server 2012 R2 Essentials Microsoft Windows Storage Server 2012 R2 Standard VMware vSphere 6.5 VMware vSphere 6.0 SUSE Linux Enterprise Server 12 Red Hat Enterprise Linux 7 Red Hat Enterprise Linux
Power supply	800 W
Cabling technology	10/100/1000Base-T(X)
Ethernet interface type	Gigabit Ethernet
Operating temperature (T-T)	5 - 45 °C
Operating relative humidity (H-H)	10 - 85 %
Certification	CB, RoHS, WEEE, GS, CE, CSAc/us, FCC Class A, VCCI, KN32, KN35, CCC, C-Tick
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	6
PCI Express slots version	3.0
On-board graphics card model	Not available
Processor ARK ID	193384

Weight and Dimensions

Depth	177 mm
Width	448 mm
Height	736 mm
