9.7.4 Replacing a riser card
Field Replaceable Unit
(FRU)
Hardware: 5 minutes
Hardware: 5 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver
Preliminary steps
▶
"Locating the defective server" on page 47
.
▶
"Shutting down the server" on page 49.
▶
"Disconnecting the power cord" on page 50.
▶
"Getting access to the component" on page 51.
▶
"Locating the defective component" on page 48.
▶
Remove the corresponding riser module, see "Removing the riser module"
on page 86.
Removing the defective riser card
▶
Remove all expansion cards installed in the riser module, see "Removing
the expansion card from the riser module" on page 367.
▶
Remove the riser card, see "Removing the riser card" on page 84.
Installing a new riser card
▶
Install the riser card, see "Installing the riser card" on page 85.
▶
Install all expansion cards in the riser module, see "Replacing an expansion
card in the riser module" on page 369.
Concluding steps
▶
Install the corresponding riser module, see "Installing the riser module" on
page 87.
▶
"Reassembling" on page 68.
Expansion cards and backup units
TX2550 M5 Upgrade and Maintenance Manual 371
