12.7 Ultraslim ODD in an ultraslim ODD adapter
12.7.1 Installing the ultraslim ODD in the ultraslim ODD
adapter
Upgrade and Repair Unit
(URU)
Hardware: 10 minutes
Tools: – Phillips PH0 / (+) No. 0 screw driver
–
Slotted screw driver (for bending in or out accessible drive
mounting brackets)
Preliminary steps
▶
"Shutting down the server" on page 49
.
▶
"Disconnecting the power cord" on page 50.
▶
"Getting access to the component" on page 51.
The front cover only needs to be removed in order to remove
accessible drive dummy covers.
▶
"Removing the system air duct" on page
67.
▶
"Removing the PCI air duct" on page
88.
▶
If applicable, "Removing the riser module" on page 86.
▶
If applicable, remove the expansion card, see "Removing an expansion
card" on page 358.
▶
Remove the fan bridge, see "Handling the fan bridge" on page 92.
▶
If applicable, "Removing the 4x 3.5-inch HDD extension box" on page 281.
Accessible drives
