Figure 55: Removing an accessible drive cover
▶
Turn the front cover face down.
▶
Press in on the lugs on either side of the drive cover
.
▶
Fold up (1) and remove the accessible drive cover (2).
4.12.6 Installing accessible drive covers
Installing accessible drive covers is illustrated by the example of the
floorstand model. In case of the rack front cover, the procedure is
identical.
Basic hardware procedures
102 Upgrade and Maintenance Manual TX2550 M5
