Fujitsu PRIMERGY TX2550 M5 - Replacing the Pcie SSD Backplane on the 8 X 2.5-Inch Pcie SSD Extension Box

▶
"Resuming BitLocker functionality" on page 130
.
7.7.2 Replacing the PCIe SSD backplane on the 8x 2.5-
inch PCIe SSD extension box
Upgrade and Repair Unit
(URU)
Hardware: 10 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver
Preliminary steps
▶
"Shutting down the server" on page
49
.
▶
"Disconnecting the power cord" on page 50.
▶
Remove all 2.5-inch PCIe SSDs SFF from the PCIe SSD extension box, see
"Removing 2.5-inch HDD/SSD modules" on page 220.
▶
"Getting access to the component" on page 51.
▶
"Removing the system air duct" on page 67.
▶
If applicable, remove the fan bridge, see "Handling the fan bridge" on
page 92.
Removing the defective PCIe SSD backplane
▶
Unlock and pull the 8x 2.5-inch PCIe SSD extension box out of its
installation bays, see "Removing the 8x 2.5-inch HDD/SSD extension box"
on page 271.
The PCIe SSD extension box has the same cage as the 8x 2.5-inch
HDD extension box but instead of the two HDD backplanes, there are
two PCIe SSD backplanes.
Hard disk drive (HDD) / solid state disk (SSD)
294 Upgrade and Maintenance Manual TX2550 M5
