Figure 77: Rack model versus floorstand model with drive cage turned
7.3 Handling HDDs or SSDs without
installation frame
7.3.1
2.5-inch HDD/SSD and 2.5-inch installation frame
Installing or removing the installation frame is only necessary for Japan.
Customer Replaceable
Unit (CRU)
Hardware: 5 minutes
Tools: Phillips PH1 / (+) No. 1 screw driver
Hard disk drive (HDD) / solid state disk (SSD)
