Preliminary steps
No steps needed.
Installing a 2.5-inch HDD/SSD in a 2.5-inch installation frame
Figure 78: Installing the 2.5-inch HDD/SSD in the 2.5-inch installation frame (A)
▶
Lay the 2.5-inch HDD/SSD into the 2.5-inch installation frame as shown.
Figure 79: Installing the 2.5-inch HDD/SSD in the 2.5-inch installation frame (B)
▶
Fasten the 2.5-inch HDD/SSD with four screws.
Hard disk drive (HDD) / solid state disk (SSD)
